UP1 - 32Bit/192kHz PRO Audio Interface

3 In 4 Out USB&OTG Portable Pro Interface

It features the high-current headphone amplifier chip from TI company, delivering a high-fidelity listening experience. The gain can reach 16dBu, with dynamic range of 124dB
High-power ear phone amplifier
It features the high-current headphone amplifier chip from TI company, delivering a high-fidelity listening experience. The gain can reach 16dBu, with dynamic range of 124dB
a Crystal amplifier with an input gain of up to 64dB, capable of driving various low-sensitivity microphones. With a 5k input impedance, it also accommodates high-impedance microphones. The mic preamp features dual amplification, providing a 20dB gain with slight coloration to enhance the recorded sound while maintaining audio fidelity.
Low-noise Mic amplifier
a Crystal amplifier with an input gain of up to 64dB, capable of driving various low-sensitivity microphones. With a 5k input impedance, it also accommodates high-impedance microphones. The mic preamp features dual amplification, providing a 20dB gain with slight coloration to enhance the recorded sound while maintaining audio fidelity.
the UP1 employs digital synchronous transmission for seamless signal transfer between mobile OTG and computer USB, providing lossless digital signals for an enhanced audio experience during live streaming
High Speed USB&OTG 2.0 Cable
the UP1 employs digital synchronous transmission for seamless signal transfer between mobile OTG and computer USB, providing lossless digital signals for an enhanced audio experience during live streaming

  • Professinal Audio Interface

    • Dual USB 2.0 high speed Interface
    • 64dB Low-noise Mic amplifier
    • Less than 5mS Loopback Latency @buffer(48) 48k
    • 16dBu High-power headphone amplifier, Max 3000mW @ 1A 5V USB Power
    • Low-latency ASIO driver design
    • 4 pairs of virtualin WDM channels for podcast
    • Usb 2.0 Phone Port is UAC2 asynchronous protocal with feedback endpoint
    • Routing to phone usb support 32Bit/192KHz
    • Phone \Pad\Dual PC straming podcast support
    • phone usb 2.0 UAC2 auto follow computer port samplerate
    • No distortion from PC to Phone streaming audio design
    • Digitally controlled analog amplifier circuit
    • Jfet high-impedanceinstrumental input
    • Powerful Mixer for Windows
    • Mac Os control pannel suport 48V and Gain
    • Support Firmware Upgrade
    • Input channel：3
    • Output channel：4
    • Microphone amplification type：deferential amplification
    • Instrumental amplification type：JFET amplification
    • Microphone gain：+9dB to +73dB
    • Microphone input impedance：5KΩ
    • Instrumental gain：-10dB to +54dB
    • Instrumentalinput impedance：1MΩ
    • Computer USB 2.0 Port Sampling rate：44.1K 48K 88.2K 96K 176.4K 192K
    • Computer USB 2.0 Port Sampling precision：32Bit
    • Phone USB 2.0 Port Sampling rate：44.1K 48K 88.2K 96K 176.4K 192K
    • 4mS Loopback Latency @buffer(48) 48k Samplerate
    • Phone USB 2.0 Port Sampling precision：32Bit
    • Microphone frequency response：20Hz-20KHz(±0.1dB)
    • Headphone output frequencyresponse：20Hz-20KHz(±0.1dB)
    • ADC dynamics range：120dB
    • DAC dynamics range：124dB
    • Headphone amplifier outputimpedance：10Ω
    • Headphone amplifier Maximum current：700mA@1A 5V USB
    • Headphone amplifier Maximum Power：3000mW @1A 5V USB
    • Headphone amplifier output gain：16dBu(±6V)
    • +48V phantom power：Support
    • Driver：WDM/AudioCore/AS102.3
    • Virtual channel：4 pairs of stereo
    • Mixing：Full channel matrix mixing
    • MAX Machine power：2.5W
    • Size:98mmX67mmX41mm
    • Weight:210g
    • OS: Windows 10 64bit 1703, MAC OS , Linux, IOS, Andriod
    • RAM Size: ≥ 4G
    • CPU Module: Intel CORE, AMD K10

Price: $199
